Production capacity: 2-75 t/h
Main Power: 15-351 kw
Monocular Cooler is one of the main equipments in rotary kiln production system. Its role is to cool the 1000～1300℃ clinker from rotary kiln to 200℃ and below by heat exchange of moving material and airflow inside the rotating barrel.
Zhongde Heavy Industries Co., Ltd. China(Mainland)
Monocular Cooler is one of the main equipments in rotary kiln production system. Its role is to cool the 1000～1300℃ clinker from rotary kiln to 200℃ and below by heat exchange of moving material and airflow inside the rotating barrel. The quality and grindability after cooling down is improved. The air from cooling clinker is injected into kiln, as secondary circulating air, raising the thermal efficiency of kiln.
Features:
This equipment can fully suck the air that is used for cooling the materials as secondary circulation air, thus improving the thermal efficiency of the kiln, and in addition, it has the features of simple structure, high running rate and convenient operation and maintenance, so that is very suitable for small-sized cement plant.
Note: please specify transmission arrangement when placing an order.
| Spec./m (Dia×Length） |
Capacity (t/h) |
Installation Obliquity (%) |
Main Reducer |
Main Motor (kw) |
Weight (t) |
| Φ1.5×15 | 2～3 | 3～5 | ZQ500 | 15 | 28 |
| Φ1.5×20 | 3～4 | 3～5 | ZQ500 | 15 | 35 |
| Φ1.8×18 | 4～6 | 3～5 | ZQ500 | 18.5 | 47 |
| Φ2.0×22 | 7～8.5 | 3～5 | ZQ500 | 22 | 61 |
| Φ2.2×18 | 7～8.5 | 3～5 | ZQ500 | 22 | 64 |
| Φ2.2×22 | 8～10 | 3～5 | ZQ650 | 30 | 73 |
| Φ2.4×24 | 12～15 | 3～5 | ZS125 | 45 | 98 |
| Φ2.5×25 | 15～20 | 3～5 | ZS125 | 55 | 110 |
| Φ2.8×28 | 16～22 | 3～5 | ZL100 | 55 | 130 |
| Φ3.0×30 | 20～25 | 3～5 | ZL115 | 75 | 169 |
| Φ3.2×36 | 28～32 | 3～5 | ZL115 | 90 | 200 |
| Φ3.3×40 | 32～36 | 3～5 | ZI130 | 132 | 237 |
| Φ3.6×36 | 35~38 | 3~5 | ZSY450-28 | 185 | 318 |
| Φ4.0×36 | 50~60 | 3~5 | ZSY450-25 | 220 | 348 |
| Φ4.0×45 | 60~70 | 3~5 | ZSY450-25 | 250 | 414 |
| Φ4.5×50 | 70~75 | 3~5 | ZSY500-25 | 315 | 576 |
